Changelog
4.8.0:
Added compute shader support to ReShade FX shader language, supported in D3D11, D3D12, > OpenGL and Vulkan. Example:
#include "ReShade.fxh"
texture testTex { Width = 32 * 2; Height = 1024; Format = RGBA8; };
storage testStore { Texture = testTex; };
sampler testSample { Texture = testTex; MinFilter = POINT; MagFilter = POINT; };
groupshared float test[32];
void Test_CS(uint3 id : SV_DispatchThreadID, uint3 tid : SV_GroupThreadID)
{
test[tid.x] = id.x / 32.0;
barrier();
if (tid.x % 2 == 0)
test[tid.x] += test[tid.x + 1];
else
test[tid.x] = 1;
barrier();
tex2Dstore(testStore, id.xy, float4(test[tid.x].xxx, 1));
}
float3 Final_PS(float4 vpos : SV_Position, float2 texcoord : TexCoord) : SV_Target
{
return tex2D(testSample, texcoord).rgb;
}
technique Compute
{
pass
{
// Specify the local thread group size as part of the compute shader assignment
// Format is "FunctionName<X, Y, Z>", but Z is optional
ComputeShader = Test_CS<32, 1>;
DispatchSizeX = 2;
DispatchSizeY = 1024;
// Can also add "DispatchSizeZ" for 3D-launches
}
pass
{
VertexShader = PostProcessVS;
PixelShader = Final_PS;
}
}
Added option to not clear alpha channel of screenshots
Added option to include preset name in screenshot file name
Added JPEG as a screenshot format option
Added option to duplicate current preset when creating a new one
Added option to only load enabled effects
Added performance mode toggle keyboard shortcut
Added global option to force fullscreen mode in D3D, ReShade.ini:
[D3D9] ; or [DXGI]
ForceFullscreen=1
Added support for global config file to change base and module load path (instead of having to rely on environment variables). To use, ceate an INI file with the same name as the ReShade DLL (e.g. dxgi.ini) next to it, with these contents:
[INSTALL]
BasePath=path/ReShade/should/use/as/base/for/all/relative/paths
ModulePath=path/ReShade/should/load/DLLs/from
Added position of separator between technique and variable list in UI to config (so it is persistent between runs)
Added technique context menu button to open containing folder in Windows explorer
Added category context menu button to reset all variables in that category to their default values
Added separate code viewer window, so one can view generated code and edit a shader simultaneously
Added editor support for “Shift + Tab” to remove line indentation without selection
Added editor support for paste on new line
Added visual indicator to text editor title when open document is unsaved
Added message to home tab when a texture failed to load
Added yellow highlight to items in the technique list where the underlying effect compiled with warnings and added those warnings to the tooltip
Added effect parser error when encountering multi-dimensional array
Added effect parser error when using sRGB sampling on back buffer but back buffer format is not RGBA8
Added effect parser error when static variable initializer is not a literal expression. This is a breaking change for some effects!
Added effect parser warning when specifying negative value for texture property
Added “tex2Dsize” intrinsic overload which takes a storage object (for compute shaders)
Added “barrier”, “memoryBarrier” and “groupMemoryBarrier” intrinsics for use in compute shaders
Added atomic intrinsics “atomicAdd”, “atomicAnd”, “atomicOr”, “atomicXor”, “atomicMin”, “atomicMax”, “atomicExchange” and “atomicCompareExchange”
Added support for “SV_IsFrontFace” semantic to GLSL/SPIR-V code generation
Added support for “min16int”, “min16uint” and “min16float” scalar and vector types
Added “mousewheel” source for uniform variables to use mouse wheel input
// Value starts at 1.0. When user moves the mouse wheel up, it goes up, but not past 10.0.
// When user moves the mouse wheel down it goes down, but not past 0.0.
uniform float value < source = "mousewheel"; min = 0.0; max = 10.0; step = 1.0; > = 1.0;
// You can also add a second component, which then holds the current wheel state
// (How much the wheel was moved this frame):
// So value.y is +1 when wheel went up, or -1 when it went down
uniform float2 value < source = "mousewheel"; ... >;
Added “overlay_active” and “overlay_hovered” source to uniform variables, which hold the index (from the top in the effect file) of the UI widget the user is currently entering a value in or hovering in the UI
uniform float value1 < ui_type = "drag"; >;
uniform float value2 < ui_type = "slider"; >;
// Is zero by default, 1 when "value1" is being modified, 2 when "value2" is being modified
uniform int active < source = "overlay_active"; >;
// Is zero by default, 1 when mouse cursor is over "value1" in UI and 2 when it is over "value2"
uniform int hovered < source = "overlay_hovered"; >;
Added more verbose logging in case of D3D10/11 resource creation failures
Added pass names for passes writing to a texture on the statistics page
Added device and driver information to UI in OpenGL
Added support for comma character in INI elements
Added path text box to app selection in setup tool
Added different sort modes to app selection in setup tool
Added button to add custom effect package to setup tool
Added option to skip individual effect selection using three state checkboxes to setup tool
Added setup tool archive validation when opening it
Added standard Epic Games Launcher install location to setup tool search paths
Added heuristic to setup tool that chooses the depth reversed setting based on the year a game came out
Added error to setup tool when installing to an application that already has ReShade installed via a different render API
Added notice on how to uninstall to final setup tool screen
Added signature to setup tool
Improved file and directory selection dialogs (including the preset selection) and added icons
Improved format of variable names in generated GLSL code for better readability
Improved effect parser error recovery for errors inside struct definitions
Improved speed of setup tool application detection
Changed INI option names for a cleaner look! The setup tool will update them when installing over an existing config, but be aware of this when doing a manual update, since some of your settings may get lost.
Changed preset path option to save as a relative path to the ReShade DLL if preset is in the same or a subdirectory
Changed “tex2Dfetch” intrinsic to accept coordinates without a mipmap level and added seprate overload which accepts a mipmap level. This is a breaking change, so make sure to update your shaders (it will continue to compile with warnings in most cases, since int4 can be implicitly casted to int2, but only behaves the same then if the passed in mipmap level was zero)!
// The declarations now look like this:
float4 tex2Dfetch(sampler2D s, int2 coords);
float4 tex2Dfetch(sampler2D s, int2 coords, int lod);
Changed D3D9 depth buffer detection logic to always run independently on each frame (fixes flickering in some games, like RE4 Remastered HD)
Changed splash banner to disappear immediately after reloading finished on all reloads except the first one
Changed assembly viewer text to get updated after an effect finished compiling
Changed HLSL compilation to enable highest optimization level only when performance mode is active
Changed configuration to save and restore custom style independently of the fixed presets (so its not lost when switching between those)
Changed keyboard shortcuts to be inactive while typing into text boxes
Changed item width for variable editor UI widgets
Changed texture name reservation to only run in OpenGL compatibility contexts by default
Changed default preset file name to “ReShadePreset.ini”
Changed setup tool to install to “bin” directory if one exists next to the executable (for Source Engine games)
Fixed mouse button double clicks not registering
Fixed red and blue color channel being switched in D3D12 screenshots in some applications
Fixed hang in Vulkan games because fence completion check was comparing against wrong return value
Fixed partial screen updates in D3D9 messing up ReShade rendering (e.g. in IL-2 Cliffs of Dover)
Fixed hooks not being installed in applications that call “LoadLibraryExA/W” with flags (e.g. Prey)
Fixed duplicated D3D10/D3D11 hooks (since the D3D10 driver may use D3D11 internally)
Fixed D3D9 depth surface replacement messing up games using INTZ format themselves (e.g. Dead Space)
Fixed artifacts in D3D9 games using partial depth buffer clears
Fixed artifacts in OpenGL games using GL_ALPHA_TEST
Fixed unbound key shortcuts potentially triggering if application sends input messages for key code zero
Fixed crash if application calls “ID3D11Device::CreateShaderResourceView” and similar with a nullptr resource (e.g. in Snowrunner)
Fixed crash when application unloads ReShade while a thread is still calling “GetMessage” (e.g. in Dolphin)
Fixed crash in Vulkan when data race occurs after multiple threads failed to access a value from a lockfree table (e.g. in Baldur’s Gate)
Fixed crash if font atlas creation fails
Fixed crash when parsing ReShade FX code that attempts a function call outside of a function
Fixed crash if ReShade FX code contains shader function with an output parameter or return value without a semantic
Fixed crash when pressing “Shift + Tab” in editor with a line that has only spaces selected
Fixed R8 and RG8 textures having an alpha value in D3D9
Fixed wrong render targets being set in D3D12 if effect contains multiple techniques
Fixed primitive topologies other than triangles not working in OpenGL
Fixed “tex2Dstore” intrinsic writing with a slight offset in OpenGL
Fixed precision of floating-point constants in generated HLSL/GLSL code
Fixed preprocessor removing spaces in macro arguments
Fixed preprocessor not trimming all whitespace before and after macro arguments and around concatenation operator
Fixed preprocessor not adding adding backslashes to escape quotes in stringize operator
Fixed code generation for switch statements with multiple cases pointing to the same block
Fixed SPIR-V code generation for struct member accesses on function return values
Fixed SPIR-V code generation for struct input parameters
Fixed SPIR-V code generation for switch statements that contain branches
Fixed SPIR-V code generation for “inout” function parameters with semantics and arrays
Fixed HLSL code generation for global “static” variables
Fixed HLSL code generation for loops on uniform variables in shader model 3
Fixed missing interpolation qualifiers in generated GLSL code for struct return values
Fixed location calculation for GLSL array input and output variables
Fixed GLSL code generation for “inout” function parameters with semantics
Fixed GLSL code generation for shaders that have multiple input or output parameters with the same semantic
Fixed effect parser error when initialization array of structs using initializer list syntax
Fixed incorrect FreePIE uniform data padding
Fixed “timeout” annotation on techniques for very small values (so one can now set it to “1” to only have the technique run a single time)
Fixed division by zero if min/max are switched for “random” uniform source
Fixed user being able to enter invalid characters as a preprocessor macro name
Fixed dragging technique to a new location not preserving order of the others
Fixed editor font affecting search and replace buttons
Fixed pooled textures not always showing up on statistics page
Fixed double click behavior on app selection list in setup tool (it now only reacts if the same item is clicked twice)
Removed “tex2Dgather” intrinsic and instead split it into separate variants for each component:
float4 tex2DgatherR(sampler2D s, float2 coords); // equal to previous "tex2Dgather(s, coords, 0);"
float4 tex2DgatherG(sampler2D s, float2 coords); // equal to previous "tex2Dgather(s, coords, 1);"
float4 tex2DgatherB(sampler2D s, float2 coords); // equal to previous "tex2Dgather(s, coords, 2);"
float4 tex2DgatherA(sampler2D s, float2 coords); // equal to previous "tex2Dgather(s, coords, 3);"
Removed separate “tex2D[…]offset” texture intrinsics and instead made them overloads
float4 tex2D(sampler2D s, float2 coords);
float4 tex2D(sampler2D s, float2 coords, int2 offset);
float4 tex2Dlod(sampler2D s, float4 coords);
float4 tex2Dlod(sampler2D s, float4 coords, int2 offset);
float4 tex2DgatherR(sampler2D s, float2 coords);
float4 tex2DgatherR(sampler2D s, float2 coords, int2 offset);
...
Removed technique percentage numbers from statistics (since they where commonly misunderstood)
Removed support for “POSITION”, “VPOS” and “DEPTH” input semantics (use “SV_Position” and “SV_Depth” instead)
Removed error limit again since it can hide errors behind a lot of warnings
4.8.1:
Added automatic texture reference tracking to effect compiler (it now knows which passes use which textures)
Improved performance of compute passes
Improved OpenGL effect rendering performance
Changed compiler to remove “static” qualifier from local variables to fix some effects failing to compile since the 4.8 update
Changed sRGB sampling check on back buffer to a warning instead of an error
Changed reference display for textures on the statistics page to a more detailed break down of where and how they are used
Changed cycle order of effect package checkboxes in setup tool
Fixed docking windows to other windows not working
Fixed compute shaders not being able to read from textures also used as storage
Fixed GLSL code generation not removing all duplicated underscore symbols in names
Fixed Vulkan textures not being cleared to zero on creation
Fixed OpenGL mipmaps looking slightly different than in the other APIs
Fixed crash on startup with RenderDoc attached
Fixed screenshot with overlay not being created for preview texture window
Fixed texture load failure message listing all textures of disabled effects too
Fixed setup tool installing to the wrong directory for “Vampire: The Masquerade” game
4.8.2:
Added missing hooks for “Direct3DCreate9on12” and “DXGIDeclareAdapterRemovalSupport”
Fixed crash when effects use pooled textures
Fixed crash in D3D9 games that have Windows compatibility fixes active (ReShade now finally works in SWTOR, when correctly installed as d3d9.dll!)
Fixed artifacts and depth buffer detection in the first “The Witcher” game
Removed global settings (“ForceFullscreen”, “Force10BitFormat”, etc.) from ReShade.ini and instead moved those into d3d9.ini/dxgi.ini/opengl32.ini file
[APP]
ForceVSync=0
ForceWindowed=0
ForceFullscreen=0
ForceResolution=0,0
Force10BitFormat=0
ReShade FX support equivalent to this version (with compute shaders) will be part of FreeStyle in the next NVIDIA driver branch release.
